DANFOSS IGNITION TRANSFORMER EBI4 1P
Item Code: 38630985098
1 / 2Product Overview
The Danfoss EBI4 1 Pin is an electronic ignition transformer built to deliver reliable intermittent ignition between a single electrode and frame in small to medium-sized oil and gas burners. As part of Danfoss’s modern EBI4 range, it’s engineered for high-frequency operation, giving it a notably low weight and compact footprint while still producing a strong, consistent spark for smooth burner start-up. This makes it a practical fit for a wide range of heating equipment, including boilers, furnaces, ovens, and kilns, where dependable ignition and easy integration matter. Backed by Danfoss’s reputation for quality and durability, the EBI4 1 Pin also serves as a trusted, straightforward replacement for older ignition transformers, helping keep burner systems firing reliably with minimal upkeep.
Technical Specifications
| Parameter | Value |
|---|---|
| Component Type | Electronic Ignition Unit / Ignition Transformer |
| Poles | 1-pole ignition |
| Primary Voltage Connection | 230 V AC |
| Primary Current | 0.25 A |
| Primary Frequency | 50/60 Hz |
| Secondary Peak Voltage | 12 kV |
| Short Circuit Current | 40 mA (rms) |
| Secondary Frequency | 20 kHz to 25 kHz |
| Duty Cycle (ED) | 33% at 60°C over a 3-minute interval / 100% |
| Operating Ambient Temperature | -10°C to +60°C |
| Enclosure Rating | IP 40 (excludes secondary connections) |
| Weight | ~259 grams |
| Earthing | Through the primary cable |
| Primary Connection | 3 x 0.5 mm² cable with special plug |
| Approvals | CE, UKCA (for specific models), RoHS and WEEE compliant |
₹2,999
